Optical Filter Mounts and Lens Holders Mounts that hold a lens where the beam expects it, and filter holders that let it be swapped. Fixed holders for 12.7, 25.4 and 50.8 mm optics with SM05, SM1 and SM2 threads. Kinematic and rotation mounts for alignment, drop in holders for quick filter changes.
Integrating Spheres and Diffuse Reflectance Standards Spheres that collect every reflected angle, and the white tiles that calibrate them. PTFE and Spectralon spheres from 30 to 200 mm, three or four ports. Calibrated standards from 2 to 99 percent, data every 50 nm from 250 to 2500 nm.
Reflectance and Transmission Probes for Spectrometers Probes that light a sample and read it back through one ferrule. Six illumination fibers around one read fiber, 200 to 600 um cores. Transmission dip probes from 2 to 50 mm pathlength for in line absorbance.
HPLC Columns for Reversed Phase Method Development Columns chosen by the method pH first. C18 and C8 chemistries, 4.6 mm and 2.1 mm bore. 5 and 3.5 um particles, 80 and 130 A pores, L1 classification.
Wavelength Calibration Lamps for Spectrometers Atomic lines, not a continuous spectrum. Five lamps covering 253 to 1984 nm, fibre coupled through SMA 905. Mercury argon for UV and visible, argon and xenon for the NIR.
Beam Dumps and Baffles for Stray Light Control Where the beam ends, on purpose. Traps and blocks from 200 nm to 12 um, 5 W to 500 W CW. Graphite, steel and ceramic absorbers, cage or post mounted.
Arc Lamp Igniters and Xenon Lamp Power Supplies Power supplies that carry the igniter inside the case. Plus 15 kV trigger pulses, 4 strikes per second, over 80,000 strikes. Cermax xenon and mercury versions, 100 to 300 W constant power.
Photomultiplier Tubes and PMT Housings for Spectrometers 28 mm side on tubes for spectroscopy and fluorescence. Multialkali to 900 nm, bialkali to 650 nm, gain of 1.0 x 10^7. Socket assemblies with the divider built in, plus D type sockets.
RTD and Thermocouple Probes for Analyser Blocks Temperature probes built for a block, not for a wall. Pt100 class A in 2, 3 or 4 wire, type K and J thermocouples in class 1. 304 and 316 sheath, M8 to G1/2 threads, sealed or exposed junction.
Diaphragm Vacuum Pumps for Analyser Vacuum Lines Oil free vacuum for sample lines, degassers and filter housings. One stage pumps hold 70 to 160 mbar, two stage pumps reach 1.5 to 7 mbar. PTFE diaphragms and FFPM valves for solvent and acid vapours.
Fiber Bundles and Light Guides for Spectrometers Bundles that match a spectrometer slit, not just a single fiber. Round to linear, bifurcated Y and fan out formats, 50 to 600 um cores. High OH, low OH and solarization resistant fibers, SMA 905 on both ends.
Filter Wheels and Automated Filter Changers Manual and motorized filter wheels for photometric and imaging benches. Six and twelve position wheels for 25.4 mm and 12.5 mm optics. Switching times from 55 ms, with USB, RS-232, TTL and BNC control.
Lamp Reflectors and Ellipsoidal Condensers Ellipsoidal reflectors and condenser assemblies for lamp housings. Rhodium on nickel ellipsoids with both focal distances given. UV fused silica and Pyrex condensers, IR versions in germanium and ZnSe.
Autosampler Vials and Septa for HPLC 2 mL autosampler vials and closures for LC and GC trays. Screw neck 9 mm and crimp neck 11 mm, clear and amber, certified lots. PTFE silicone, sandwich and BTO septa, quoted as matched sets.
Neutral Density Filters and Photometric Reference Standards Neutral density filters and certified references for photometers. Absorptive ND filters in optical densities from 1.0 to 4.0 on 25 mm mounts. Schott NG glass references certified at 440, 465, 546.1, 590 and 635 nm. Holmium and didymium filters for wavelength checks, with NIST traceability.
Column Ovens and Heater Blocks for HPLC Compartments Column ovens and heater blocks that hold an HPLC column at temperature. Peltier ovens from 4.0 C to 70.0 C, heating only ovens from 20.0 C to 90.0 C. Aluminium block heaters to 150 C for columns up to 50 cm long. Stability of 0.1 C to 0.2 C, PID control and over temperature protection.
Optical Windows and Sapphire Discs for Detector Ports Windows and sapphire discs that seal a detector or sample port. UV fused silica from 185 nm, N-BK7 for visible work and sapphire for harsh ports. Thickness options from 1.0 mm to 12.0 mm in four AR coating bands. Flat, parallel and cleanable, with tolerances stated per size.
Tube Fittings and Ferrules for Reagent Lines Flangeless fittings and ferrules for analyser and HPLC reagent lines. 1/4-28 flat bottom, 10-32 coned and M6 ports for 1/16 and 1/8 inch tubing. ETFE ferrules to 2000 psi, PEEK and stainless two piece sets to 9000 psi. Nuts and ferrules listed separately so a single worn part can be replaced.
Needle and Metering Valves for Analyser Lines Needle, metering and splitter valves for analyser and LC MS lines. Adjustable flow down to 3.5 uL per minute from a 1 mL per minute inlet. PEEK and PTFE wetted path rated to 800 psi, graduated splitter to 4000 psi. 1/4-28 flat bottom and 10-32 coned ports for 1/16 and 1/8 inch tubing.
Lenses and Mirrors for Optical Benches Plano convex lenses and mirrors for photometric and analyser benches. N-BK7 lenses with three AR coating ranges from 350 nm to 3.0 um. Protected silver mirrors at 97.5% average reflectance from 450 nm to 2 um. Concave mirrors for focusing and relay paths, 1 inch body, 100 mm focal length.
Fiber Collimators and Patch Cords for Photometric Probes Collimating lenses and patch cords for photometric probes and dip cells. Lens options from f/2 at 10 mm focal length up to f/4 at 100 mm for long throw. Fixed focus FC/APC collimators at 543 nm and 1550 nm in a 12 mm body. Step index cords from 105 um to 600 um core in high OH and low OH glass.
Dichroic Filters and Beam Splitters for Photometric Channels Dichroic mirrors and beamsplitters for 45 degree photometric channels. Cut on wavelengths from 505 nm to 900 nm in 1 inch and 25 x 36 mm sizes. Plate splitters in five ratios and non polarizing cubes from 10 mm to 1 inch. Obsolete dichroics sourced on a last time buy basis against the original number.
Xenon and Deuterium Lamps for Photometric Instruments A photometer is a lamp with an optical bench in front of it, and the lamp sets both the wavelength range and the noise floor. Deuterium covers the deep UV with a continuum that reaches 115 nm on a fluoride window; xenon covers 185 nm to 2,000 nm with a small, bright arc. The parts below run from a 75 W xenon arc with a 1.3 mm source size up to a 300 W forced air lamp, and from a 2,000 hour long life deuterium body down to a 1,000 hour high intensity type. Window material is the number that decides the short wavelength cut off: UV glass stops at 185 nm, synthetic silica reaches 160 nm, and a magnesium fluoride window reaches 115 nm. Each line gives the drive figures, the guaranteed life and the trigger voltage together, because a lamp that matches the optics and not the starter will not light.
Immersion Assemblies and Sample Probes for Online Analysers A pH or conductivity sensor is only as good as the point it sits in. An immersion assembly holds the probe at a depth where the reading is representative, seals the vessel, and lets a technician reach the sensor without draining the tank. The bodies below run from a polypropylene dip tube for an open channel up to a stainless retractable body rated 10 bar at 140 C, with hygienic versions that take 30 minutes of saturated steam at 120 C. Immersion depth runs from 48 mm on a short retractable body to 3,000 mm on a dip tube, and the process connection is a DN 100 or DN 80 flange, an ANSI 3 in flange, or a G 1 1/4 thread. Each line gives depth, pressure, temperature and wetted material together, because the depth that fits a tank and the pressure that fits a pipe rarely come from the same body.
Inline Filters and Frits for Reagent Lines A reagent line fails quietly. The pump seal wears, the injection valve rotor sheds a few particles, a buffer precipitates at the first cold spot, and the damage shows up as a rising back pressure or a split peak rather than as a leak. The filters below cover the three places that matter: an inlet cup in the reservoir, an inline body between the pump and the valve, and a precolumn body just ahead of the column. Pore size runs from 0.2 to 20 micron, swept volume from 10 nL to 103 microlitre, and the wetted path is 316 stainless steel, PEEK or titanium, so the same family covers an HPLC line and a clinical reagent path. Each line gives the pore size, the swept volume and the pressure rating together, because a filter chosen on pore size alone can add more dispersion than the column can absorb.
Inline Degassing Modules and Vacuum Degassers for Liquid Lines Dissolved gas leaves a liquid when the pressure drops, so a degasser works by giving the gas somewhere to go before the liquid reaches the detector. The parts below are membrane degassing chambers from 20 to 800 millilitres per minute, with the flow at which each one removes half the dissolved oxygen stated on the line. Each entry gives the flow for 50 percent removal, the fluid volume inside the chamber, the vacuum level and the connections, so a chamber is matched to the pump rather than to the box size. The vacuum side is quoted as a pressure and a volume, because the pump and the chamber are one system and neither works at its rating alone.
Syringe Pumps and Precision Dispensers for Analysers A syringe pump delivers volume by moving a plunger, so the number that matters is not the flow rate but the resolution of that movement. The parts below cover 60 mm stroke OEM pumps from 25 microlitres to 50 millilitres per stroke, with step counts from 6000 up to 384000 on a smooth flow version. Each entry gives resolution, speed range, precision, accuracy and the syringe sizes the frame accepts, so the pump is matched to the volume before it is matched to the protocol. The slowest speed is quoted as a stroke time rather than a flow, because a nanolitre per minute flow is easier to read as hours per stroke.
Rotary and Injection Valves for Analyser Sample Paths A sample path is only as repeatable as the valve that switches it, and the two numbers that decide that are the internal volume and the pressure rating. The parts below cover six port injection valves with 20 microlitre loops rated to 345 bar, and multiposition selector valves from 4 to 16 ports. Each entry gives port count, bore or loop volume, maximum pressure, maximum temperature and the fitting, so the valve is matched to the pump and to the tubing. Loop volume tolerance and the filling method are stated as well, because a nominal 20 microlitre loop does not deliver 20 microlitres.
Bandpass and Interference Filters for Photometric Channels A bandpass filter is specified by two numbers that are often confused, the guaranteed bandwidth that carries the transmission and the full width at half maximum. The parts below run from 340 to 1055 nm with guaranteed bandwidths from 6 to 90 nm, and every one is a hard coated single substrate filter in a 25 mm ring. Each entry gives centre wavelength, bandwidth, average transmission across the passband and the blocking levels on either side. The passband figure is quoted as an average over a stated band, because a peak transmission number tells nothing about what the channel sees at its edges.
Quartz Flow Cells and Cuvettes for Photometric Instruments In a flow cell the optical path and the volume pull against each other, and the method decides which one gives way. The parts below cover all quartz flow cells from 0.1 to 50 mm path with volumes from 6 to 3200 microlitres, plus cuvettes for batch work with a held path length tolerance. Each entry gives path length, centre height, outside dimensions, aperture and volume, so the cell is matched to the light beam and to the tubing that feeds it. Window material is listed with the wavelength band it transmits, because a quartz cell and an optical glass cell are not interchangeable at 340 nm.
Inline Fluid Heaters and Peltier Chillers for Analysers Heating a flowing liquid is a race between the power going in and the heat the tube takes out, and the number that settles it is watt density, not wattage. The parts below cover layered inline heaters from 250 W to 4 kW with water side densities up to 70 W per square centimetre, and thermoelectric chillers that hold a closed loop between minus 12 and plus 40 C. Each entry gives voltage, wattage, heated length, the number of zones and the density at that length, so a heater is chosen from the flow and the temperature rise rather than from the label. Chillers are listed with cooling capacity, control range and the interface, because a chiller that cannot be read by the instrument controller is a chiller that runs open loop.
Conductivity Cells and Toroidal Sensors for Water Analysers A conductivity reading is only as good as the cell constant, and the cell constant is the number that changes when the electrodes foul or the cable is extended. The parts below cover graphite and stainless steel contacting cells from k 0.1 to k 10, and toroidal sensors that reach 2000 mS/cm without any metal touching the sample. Each entry gives cell constant, wetted material, temperature and pressure limits and the fitting, so a cell is chosen for the range and for the pipe it goes into. Temperature compensation is listed with the element type, because a 10 k thermistor and a Pt1000 do not answer the same way at the top of the range.
pH and ORP Electrodes for Process Analysers An electrode that drifts is usually blamed on the glass, but on a process analyser the reference is the part that fails first. The parts below cover steam sterilizable in-line pH sensors with a pressurised reference, sealed gel electrodes for sampling lines, and platinum or gold ORP electrodes for redox control. Each entry lists pH or mV range, temperature and pressure limits, junction type and connector, so the electrode is matched to the process before it is matched to the meter. Slope, offset and response time are given where the maker publishes them, because a two point buffer check only proves the electrode still answers.
UV and Visible LED Sources for Photometric Detection A photometer does not care how bright an LED looks, it cares how much radiant power arrives at one wavelength, and that figure is quoted in milliwatts rather than lumens. The parts below run from 255 nm to 627 nm and cover the bands a fixed wavelength photometer uses, with spectral width from 10 nm to 30 nm. Each entry gives the peak or dominant wavelength, the radiant power or flux at its test current, the forward voltage and the package. The deep UV parts deliver microwatts to a few tens of milliwatts, so the optical path and the detector gain are decided before the LED is chosen.
Air Bubble Detectors for Infusion and Reagent Lines An air bubble detector is chosen by the smallest bubble it must catch and by the tube it has to clamp, and those two figures decide the principle. The parts below cover ultrasonic transmission sensors from 1.8 mm to 15.5 mm channel width and optical types for 2 to 4 mm tube, with a response time down to 20 microseconds. Every entry lists the bubble size that is detected reliably, the tube outer and inner diameter, the output and the ingress protection. The trade is simple: ultrasound works through opaque tubing and sees a fraction of the inner diameter, optics need a clear tube and see a fixed air gap.
Fluid Check Valves and Shuttle Valves for Reagent and Pneumatic Lines A check valve in a reagent line is a pressure gate, and the figure that decides whether the line works is the cracking pressure, not the body size. The parts below cover diaphragm, umbrella, duckbill and spring check valves from 0.11 psi to 10 psi cracking, plus shuttle valves for choosing between two pneumatic sources. Cracking pressure is quoted with the spring tolerance, because a 3 psi nominal spring is allowed to open anywhere from 2.1 to 3.9 psi. Every entry lists body material, seal material, connection and maximum working pressure, so the valve is matched to the reagent before it is matched to the tube.
Medical Isolation Transformers for Diagnostic and Laboratory Equipment A medical isolation transformer separates the mains from the instrument, and the figure that proves it did its job is the leakage current, not the isolation voltage. The parts below are toroidal transformers from 50 VA to 3,000 VA with dual primary and dual secondary windings, 5 kVrms isolation and leakage under 100 microampere. Each rating is listed with its outline, its height and its weight, because a 3,000 VA toroid has to fit a chassis before it can be ordered. The leakage limits from IEC 60601-1 are listed next to the parts, because the transformer is only one contributor to the figure the finished instrument has to meet.
Quick Disconnect Couplings and Luer Fittings for Reagent Lines A coupling on a reagent line is opened every time a bottle is changed, and what it does at that moment decides whether the instrument needs a wipe down. The parts below split into valved quick disconnects that shut both halves on separation, and luer fittings that join small bore tubing inside a manifold. Flow coefficients run from 0.6 on a non spill coupling to 1.4 on a quarter inch valved coupling, and the spill volume per disconnect is quoted on the non spill version. Each entry lists pressure, temperature, wetted material and tubing size, because a coupling is chosen by the tube it has to fit before it is chosen by the flow.
Particulate Matter Sensor Modules for Air Quality Monitors A particulate matter sensor counts and weighs what floats in the air, and the channel list it reports is as important as the accuracy. The modules below use laser scattering with a fan to pull a known volume past the beam, so the reading is a mass concentration in micrograms per cubic metre. One reports six size bins from 0.3 to 10 micrometre, the other reports PM1, PM2.5, PM4 and PM10 plus a number concentration for each. Both are quoted with the sample volume, the response time and the laser class, because those three decide how the reading behaves in a duct.
NDIR and Photoacoustic CO2 Sensor Modules for Medical and Building Use A CO2 module is a light source, a gas cell and a detector, and the number it reports depends on how the baseline is maintained. The modules below cover two optical methods: non dispersive infrared with a long cell, and photoacoustic detection in a small cavity. Specified ranges run from 400 to 2,000 ppm for room air up to 400 to 5,000 ppm for incubators and breathing gas. Each part is listed with its accuracy band, its response time and the self calibration behaviour, because that last figure decides whether a module can be used where fresh air never arrives.
