Flexible Conduit and Fittings for Panel and Machine Wiring Galvanised steel flexible conduit in six sizes from 16 to 50 mm with stated outside diameter, inside diameter and bend radius. Overbraided steel conduit for runs that rub on a moving arm. Adaptalok ATS straight fittings in M20 and M25, IP66 as standard and IP69K with the ALS seal. Nylon fine pitch conduit for tight runs inside a cabinet.
Power Distribution Blocks for Panel Feeds Open style power distribution blocks, UL 1953, 1000 V AC and DC. Ampere ratings from 65 A to 310 A, with aluminium and copper figures stated apart. One, four or ten openings per pole, in one, three and four pole bodies. Adder poles stack in the field without tools.
Enclosure Heat Exchangers for Dusty and Sealed Sites Six wall-mounted air to air heat exchangers from 17.5 to 90 W/K. Internal circuit IP54 and external circuit IP34, so dust stays outside. 230 V and 115 V versions with electronic control and digital display. Air throughput 265 to 945 m3/h, weights 10 to 34 kg.
Enclosure Hygrostats and Humidity Controllers Mechanical hygrostats with 40-90% RH and 50-100% RH setting ranges. Electronic units with relay output and combined thermostat control. DC versions switch 20-56 V heater loads directly. All units clip to 35 mm DIN rail inside the cabinet.
Levelling Feet and Castors for Floor Standing Enclosures Levelling feet with 10 to 115 mm adjustment and 3000 to 5500 N static load. Twin castor sets rated 40, 75 and 120 kg per castor. Threads M10 x 20, M12 x 20 and M12 x 40 for the common base systems. Base and plinth adaptors quoted with the feet or the castor set.
Surge Protective Devices for AC Distribution Boards Type 2 and Type 1+2 surge devices for 230/400 V and 240/415 V systems. Nominal discharge 20 kA and 12.5 kA, maximum discharge 40 kA and 50 kA. Uc 275 V and 335 V versions, 2 pole and 4 pole, with or without remote contact. Replacement plugs and 35 mm DIN rail mounting.
Enclosure Air Conditioners for Sealed Cabinet Cooling Blue e+ wall mounted cooling units from 1.6 to 5.5 kW. Multi-voltage 110 to 240 V single phase and 380 to 480 V three phase. Internal circuit IP55, UL Type 12 and 3R, R-513A refrigerant. Integral condensate evaporation and speed controlled fans.
DIN Rail Terminal Blocks for Control Panel Wiring UT and UK screw terminal blocks from 2.5 to 6 mm2, rated 800 to 1000 V. Nominal currents from 24 to 41 A, with 32 to 57 A maximum load current. Grey feed-through and green-yellow PE versions in the same width. End covers, partition plates and end stops quoted with the strip.
Steel and Aluminium DIN Rails for Control Cabinets NS 35/7,5 and NS 35/15 rail in steel and aluminium, 2 m lengths. Perforated and unperforated profiles to EN 60715. Short time current 1.92 kA for 1 s on the 7.5 mm steel profile. End caps and end stops quoted with the rail, cut to panel width on request.
Lockout Hasps and Safety Tags for Maintenance Steel, aluminium, nylon and stainless hasps taking 2 to 24 padlocks. Safety padlocks with 4.76 mm and 6 mm shackles, key retaining or snap lock. Breaker, plug and gate valve lockout devices by isolation point. Do Not Operate tags in paper, polyester and heavy duty laminate.
DIN Rail End Stops and Terminal Partition Plates End stops for NS 35/7,5 and NS 35/15 rail in 9.5 mm and 5.15 mm widths. End covers and partition plates in 1.8 mm and 2.2 mm thickness. PA bodies rated UL 94 V-0, operating range -60 to 105 C. Parts matched to UT, UK and CLIPFIX terminal series by part number.
Enclosure LED Lamps and Door Switches for Cabinet Lighting LED system lights from 400 to 1200 lumens in four body lengths. 100 to 230 V AC, 24 V DC and 24 to 56 V DC versions share one mounting pattern. Door-operated switches, motion detectors and through-wiring accessories. IP20 interior lights with a turnable Fresnel cover for even panel lighting.
Filter Fan Units and Exhaust Filters for Enclosure Cooling Fan-and-filter units from 20 to 770 m3/h in seven cut-out sizes. Installed airflow drops 10 to 25 percent once the outlet filter and mat are fitted. IP54 standard, IP55 with a fine mat, IP56 with a hose-proof hood. Pfannenberg and Rittal units quoted with outlet filters and spare mats.
Signal Towers and Stack Lights for Machine Status 60 mm and 70 to 73 mm LED signal towers for machine status. Module current from 40 to 80 mA per element sets how many tiers the rail can carry. IP65 to IP66 with Type 4, 4X and 13 ratings on the Eaton range. Bases, tubes and spare modules quoted with the stack.
Nameplates and Engraved Panel Labels for Equipment Engraved laminate nameplates carry the marking inside the material. Polyester and metallised label stock covers serials and barcodes. Aluminium and polycarbonate device markers for small fields. Adhesive, drilled and snap-in fixing per part number.
Busbars and Earth Bars for Panel Power Distribution Flat busbar system components for panel power distribution, from the support and the 2400 mm copper bar to the spacers, claws and covers. One bar stack carries up to 1900 A at 600 V with a 100 kA short circuit rating when the supports are at 450 mm spacing. Neutral and PEN rails, end covers and edge covers complete the run, and the torque for every connection is on the sheet.
Tamper Evident Seals and Security Labels for Enclosures Plastic pull tight seals, fixed and adjustable, from 13 lbf to 40 lbf, for cabinet doors, meter boxes, tote boxes and service hatches. High security bolt seals to ISO 17712:2013 with pull apart strength from 4,100 lbf to 6,475 lbf for containers and trailers. Numbered, bar coded and printed security labels are supplied with the customer artwork on the same order.
Dust Caps and Connector Covers for Unused Ports Protective caps that close an unused M12 or RD24 port to IP67, on cable connectors, panel sockets and front fastened receptacles. The cap is moulded in PA66 or PBT with a PUR strap, and it holds -40 C to +85 C with the connector mated. A cap on an open port keeps dust, wash water and swarf out of the contacts between builds and between services.
Adhesive Standoffs and PCB Mounting Pads for Board Fixing Nylon standoffs on a double sided adhesive base, from 3.5 mm to 19.1 mm, for a board that has no room for a mounting hole or a screw boss. The pad sticks to the chassis, the board snaps onto the locking head, and a release tab lets the board come off again without tools. Three head sizes cover 1.2 mm to 1.6 mm board thickness, in a body rated UL94 V-2.
Slotted Wire Duct and Cable Trunking for Panel Wiring Slotted PVC wire duct for panel wiring, in a narrow 5 mm slot and a wide 7.9 mm slot, with eight wall sizes from 1 x 3 in to 4 x 4 in. Bases and covers are separate part numbers, and the duct is lead free PVC rated UL94 V-0 for 50 C continuous use. Finger score lines let a side wall be opened where a wire leaves the run.
Enclosure Panel Heaters and Thermostats for Cold Cabinets PTC panel heaters from 10 W to 150 W without a fan and 235 W to 870 W with one, all on 110 to 240 V supplies. The thermostat, hygrostat and digital controller are separate lines, because the heater has no set point of its own. Sizing runs from the cabinet surface area and the lowest ambient, not from the heater that fits the space.
Split Loom Conduit and Cable Sleeves for Harness Routing Corrugated loom tubing with a lengthwise slit, from 7 mm to 47 mm inside diameter, in polyethylene for indoor harnesses and nylon for heat. Flame retardant grades add a UV resistant option, and all sizes are supplied on reels with a matching clamp range. The slit wall means an existing bundle is wrapped without removing the terminals.
Cable Entry Plates and Brush Grommets for Cabinet Bases Split cable entry frames that match the cut-out of a 10, 16 or 24 pin connector, so a harness with moulded plugs passes through a cabinet base without being cut. The range covers IP54 grommet frames in zinc plated steel or V2A, and brush plates for airflow with dust screening on the same cut-outs. Sizes run from a 46 x 46 mm instrument cut-out to a 112 x 126 mm frame that carries 90 cables.
Viewing Windows and Display Bezels for Enclosure Panels A viewing window is a gasketed hole in a door, and the cut out is always larger than the viewing area by the width of the frame. The bolt on kits here use a 6.35 mm polycarbonate pane in a 14 gauge steel frame, rated UL Type 12, 3R, 4 and 4X on the stainless versions. Module windows from 60 x 77 mm to 377 x 331 mm cover a plastic case or a meter panel, in clear or smoked polycarbonate, from IP54 to IP66. Acrylic glazed covers for 19 inch racks run from 3 U to 9 U with a lock insert, for a panel that has to be read and not opened.
DC Axial Fans for Enclosure Cooling A fan is chosen by the airflow it delivers at the pressure the enclosure imposes, not by the free air figure on the front of the catalogue. The range here runs from a 40 mm frame at 7 CFM to a 120 mm frame at 120 CFM, in 5, 12, 24 and 48 V, with ball, sleeve and vapo bearings. Static pressure, noise and current are listed per part number, so the working point can be read against a filter and a louvre. Sealed sleeve and IP rated versions cover dusty and washed down cabinets, with 70,000 hour L10 life at 40 C on the ball bearing parts.
Cam Locks and Key Locking Latches for Enclosure Doors A cam lock holds a door with a cam that swings behind the frame in a quarter turn, and a compression latch adds a 6.4 mm pull up that squeezes the gasket. The family here covers 13.5 mm and 19.1 mm bodies in zinc plated steel, aluminium, 304 and 316 stainless and moulded stainless, keyed and tool operated. Grip is the number that decides the part: door thickness plus compressed gasket plus frame thickness, with a 3.2 mm to 58 mm range across the cams listed. Every latch is rated 450 N static load and reaches NEMA 4 and IP65 with the flange gasket fitted.
Holding Magnets and Magnetic Catches for Doors A magnetic catch holds a door closed with no moving parts, so it tolerates a frame that is out of line and a door that has warped a little. The catches here run from 24 N on a small round snap in body to 105 N on a double magnet rectangular body, in polypropylene. A non metallic door or frame needs a steel strike plate, because the magnet has nothing to pull against otherwise. The neodymium discs listed alongside run from 0.84 lb to 18.94 lb of pull at 80 C maximum operating temperature.
Compression and Battery Contact Springs for Enclosures A battery contact is a spring, and the pressure it puts on the cell is what keeps the circuit closed through a cold morning and a dropped case. The Keystone contacts here cover A, AA, C, CR2 and 17 to 19 mm cells, in steel with a nickel plate and a spring steel arm. The compression springs run from a 0.5 in free length at 0.68 lb per in to a 1.22 in free length at 134 lb per in, in 302 and 304 stainless. Rate, solid height and maximum load are stated, so the spring is chosen against the space rather than by eye.
Solder Wire Paste and Preforms for Board Assembly Solder is chosen by alloy first, then by flux class, then by the form the process needs: wire for a hand joint, paste for a stencil, a preform for a seam. SAC305 melts at 217 to 219 C and Sn63Pb37 at 183 C, and that 35 C gap is what a reflow profile and a hand iron are both built around. Wire on this page runs from 0.015 in to 0.062 in with a 50, 58 or 66 core, in no clean, water soluble, RMA and RA fluxes. Paste is Type 3 powder at 90 percent metal, with a stencil life of eight hours and a six month shelf life at 0 to 10 C.
Anti Vibration Mounts and Rubber Isolators A cylindrical mount isolates a chassis from a frame by putting a rubber section between the two, and the load per mount is the figure that selects it. The bobbins here run from a 20 lb axial load on an M4 thread to 2100 lb on an M16 thread, in natural rubber at 55 Shore A. Four body styles cover male both ends, male and female, female both ends and a bumper type for a panel that rests on the mount. Shear load is limited to 20 percent of the axial figure, which is the rule that most often decides the mounting layout.
Captive Panel Screws and Quarter Turn Fasteners A captive screw stays in the panel when the joint opens, so the fastener cannot be dropped inside a rack or lost on a bench. The self clinching parts here cover M3 to M6 and number 4-40 to number 8-32, with a 5.56 mm to 9.53 mm hole in the sheet. Quarter turn fasteners run from a 2.3 mm to a 15.9 mm total material thickness, selected by a stud length code from 100 to 580. Both families are ordered by the panel stack, not by the screw thread alone.
Ring Terminals and Spade Connectors for Panel Wiring A ring terminal is fixed by the stud it fits and the wire it takes, and the hole diameter is the number that most often goes wrong. The parts here cover 22-18, 16-14 and 12-10 AWG in bare, vinyl and nylon insulated versions, on studs from number 6 to 3/8 in. Hole diameters run from 0.147 in on a number 6 stud to 0.392 in on a 3/8 in stud, which is the clearance a washer needs. Fork and locking fork terminals are on the page for a stud that is loosened rather than removed.
Silicone O Rings and Sealing Gaskets for Enclosures An O ring seals on squeeze, and the squeeze comes from the groove rather than from the ring, so the dash number and the groove are read together. The AS568 sizes here run from a 4.47 mm inside diameter on a 1.78 mm section up to a 63 mm inside diameter on a 3.53 mm section. Closed cell silicone sponge covers the flat lid gasket, with a 35 to 90 kPa compression deflection depending on the grade. Silicone holds its elasticity from about minus 60 C to 200 C, which is why it is the usual choice for an outdoor cabinet.
Continuous and Butt Hinges for Enclosure Doors A continuous hinge spreads the load along the whole door edge, and a butt hinge puts it on two leaves and four to eight screws. The piano hinges here run from a 20 mm leaf on a 348 mm length to a 101 mm double knuckle leaf on a 1828 mm length. Double knuckle types rotate 270 degrees, which lets a lid rest flat against the case instead of standing proud. Butt hinges cover 39 x 39 mm up to 4 x 4 in, in zinc, black and stainless, with the hinge stop listed alongside.
Draw Latches and Toggle Latches for Enclosure Doors A draw latch pulls a door closed and holds it with an over centre action, so the clamping force and the keeper position are what decide the fit. The over centre latches here run from 135 N in the small size to 670 N in the medium heavy duty size, in steel, zinc plated steel and stainless. Pull action toggle latches cover 1600 to 8900 N, with a threaded U hook that takes up 9.1 to 24.6 mm of adjustment on the door. Latch and keeper are separate parts on the over centre range, so both are quoted together and both appear on the door drawing.
Eyelets and Rivets for Panel and Board Fixing An eyelet lines a hole and gives a screw or a pin a metal seat, and its length is chosen from the panel stack, not from the hole size. The brass eyelets here run from a 0.062 in barrel to a 0.156 in barrel, with flanges from 0.125 to 0.245 in and four mounting hole sizes. Lengths under the flange cover 0.062 to 0.250 in, so a 1.6 mm board and a 6.4 mm panel stack are both served by the same page. Nylon snap rivets cover panel stacks from 0.051 to 0.335 in and press in without tooling, which is the route for a cover that may come off again.
Butt Splices and Crimp Connectors for Wire Joins A butt splice joins two wires end to end, and the barrel length and the wire stop are what decide whether the joint holds. The parts here run from a 26-22 vinyl splice to a 12-10 sealed heat shrink splice, in vinyl, nylon, polyolefin and NiAc insulation. Voltage follows UL 486C at 600 V for most parts, with the 12-10 vinyl splice down at 300 V when a 10 AWG solid wire is used. Strip length and crimp tool are listed per family, because a 5/16 in strip in a 9/32 in barrel leaves copper outside the crimp.
Braided Sleeving and Expandable Sleeves for Harness Protection Braided sleeving protects a harness against abrasion and still lets it bend, which is why it is used where a conduit would be too stiff. The self-wrapping sleeve here runs from 3.2 mm to 50.8 mm nominal, with a 10 mil PET braid, a 25 percent edge overlap and walls from 0.61 mm to 0.97 mm. The expandable sleeve covers 1.59 mm to 50.8 mm nominal and opens to between 1.5 and 1.75 times its nominal size, which is what lets it pass a connector. Nominal size, expansion range, wall thickness and temperature are given per part number.
Wire Ferrules and Crimp Sleeves for Terminal Blocks A stranded wire in a screw clamp spreads, and a ferrule is what turns the strands into a solid pin that the clamp can hold. The ferrules here run from 0.5 mm2 at 1.1 mm ferrule diameter to 2.5 mm2 at 2.3 mm, in 14 mm sleeve length with 8 mm contact length. Twin ferrules take two 2.5 mm2 conductors into one 10 mm contact range, for a terminal that has to take a pair. Conductor size, sleeve length, contact length, ferrule diameter and stripping length are given per size, because the collar is what decides fit.
Cable Markers and Wire Labels for Harness Identification A harness is only as good as the legend on it, and the legend survives only if the marker is the right size for the wire. The slide on markers here cover 1.0 to 3.0 mm, 2.0 to 5.0 mm and 4.0 to 9.0 mm bundles, in PVC rated from -65 to 105 C. The printable tags cover 5.5 mm to 15 mm widths and 50 mm to 100 mm lengths, in halogen free polyolefin tied with a cable tie up to 4.6 mm wide. Bundle range, length, material and temperature are given per type, because a marker that is one size out slides along the wire.
