AD9363BBCZ
Brand: ADI
The AD9363BBCZ is a high-performance 2×2 RF Agile Transceiver™ purpose-built for 3G and 4G femtocell base stations. It combines best-in-class receiver sensitivity (−122dBm), ultralow transmitter EVM (−34dB), and a highly integrated direct-conversion architecture spanning 325MHz to 3.8GHz. With SPI + UART control, RSSI, and AGC, it delivers carrier-grade small-cell performance — also popular in PlutoSDR and open-source SDR platforms.
Product Specifications
Key Specifications
325 MHz – 3.8 GHz
Frequency Range
2 Tx / 2 Rx
2×2 MIMO Channels
<200 kHz – 20 MHz
Channel Bandwidth
144-Ball CSP-BGA
Package (10 mm × 10 mm)
12-bit DAC/ADC
Integrated Data Converters
−40°C to +85°C
Operating Temperature
* Typical values. Refer to the Analog Devices AD9363 datasheet for full specifications.
Technical Specifications
| Manufacturer | Analog Devices |
| Part Number | AD9363BBCZ |
| Type | RF Agile Transceiver |
| Frequency Range | 325 MHz to 3.8 GHz |
| Channel Bandwidth | Less than 200 kHz to 20 MHz |
| TX / RX Channels | 2 Transmitters, 2 Receivers (2 × 2 MIMO) |
| Duplex Mode | TDD and FDD |
| DAC / ADC Resolution | 12-bit |
| Supply Voltage | 1.267 V to 1.33 V (1.3 V typical) |
| Package / Case | 144-Ball CSP-BGA (10 mm × 10 mm) |
| Interface | LVDS, CMOS |
| Operating Temperature | −40°C to +85°C |
| TX EVM (typical) | ≤ −40 dB |
| RX Noise Figure (typical) | 2.5 dB at 800 MHz |
| Integrated PLL | Fractional-N synthesizer |
| RoHS | Compliant |
| Moisture Sensitivity Level | MSL 3 (168 hours) |
Product Description & Applications
Product Description
The AD9363BBCZ is a complete 2 × 2 RF agile transceiver from Analog Devices, integrating all RF front-end, mixed-signal, and digital baseband functions in a single 144-ball CSP-BGA package. The device provides programmable bandwidth and a frequency range covering most licensed and unlicensed bands from 325 MHz to 3.8 GHz, making it suitable for a wide range of wireless communication applications.
The device features two independent direct-conversion receivers with state-of-the-art noise figure and linearity. Each receive subsystem includes independent automatic gain control (AGC), DC offset correction, quadrature correction, and digital filtering. The two transmitters use a direct-conversion architecture with high modulation accuracy and ultra-low noise.
Target Applications
Software-Defined Radio (SDR)
Femtocell and picocell base stations
Wireless video and data transmission
General-purpose broadband radio systems
Test and measurement equipment
Point-to-point microwave links
Unmanned aerial vehicle (UAV) datalink
IoT and M2M communication gateways
Why Source AD9363BBCZ from Superb Automation
Factory-Direct Supply
Direct procurement from authorized channels in China. No middlemen, competitive pricing.
Quality Assurance
100% original Analog Devices parts. Full visual inspection and electrical testing before shipment.
Global Logistics
DHL, FedEx, UPS, and TNT shipping worldwide. Typical delivery within 3-7 business days.
Inventory Ready
AD9363BBCZ in stock. Small to medium volumes shipped same day upon order confirmation.
Technical Support
Engineering team available for integration support, reference design review, and PCB layout guidance.
Long-Term Supply
Stable supply chain. Support for production ramp-up and scheduled delivery programs.
Frequently Asked Questions
What is the frequency range of AD9363BBCZ?
The AD9363BBCZ operates from 325 MHz to 3.8 GHz, covering most licensed and unlicensed wireless bands.
What is the difference between AD9361 and AD9363?
The AD9363BBCZ offers similar functionality to the AD9361 but with a reduced channel bandwidth (20 MHz max vs. 56 MHz) and slightly different performance parameters, making it a cost-optimized option for narrowband applications.
Does the AD9363 support MIMO operation?
The AD9363BBCZ provides 2 transmitters and 2 receivers, enabling 2 × 2 MIMO operation. For higher-order MIMO, multiple AD9363 devices can be synchronized.
What is the minimum order quantity?
Superb Automation supports flexible order quantities. Contact our sales team at Info@superb-tech.com for volume pricing and availability.
Is the AD9363BBCZ RoHS compliant?
Yes, the AD9363BBCZ is fully RoHS compliant and lead-free.
