TPS79118DBVR
Product Specifications
TPS79118DBVR
Texas Instruments — Power Management & Signal Chain
Product Overview
The TPS79118DBVR from Texas Instruments is a power management / signal chain IC delivering high efficiency, precision regulation, and robust protection. Texas Instruments (TI) is a global leader in analog ICs, power management solutions, and embedded processors.
Superb Automation partners with leading brands including Qorvo, TI, ADI, XILINX, NVIDIA, Intel, ST, MACOM, Renesas, and Coilcraft to provide complete BOM and supply-chain solutions.
Key Features
- High-efficiency power conversion with low quiescent current
- Wide input voltage range with precision output regulation
- Integrated over-current, over-temperature, and short-circuit protection
- Small footprint packaging for space-constrained designs
- AEC-Q100 qualified options available for automotive applications
- Flexible sequencing and soft-start control
Key Specifications
| Input Voltage | V |
| Output Voltage | V |
| Output Current | A |
| Switching Frequency | kHz |
| Efficiency | % |
| Quiescent Current | µA |
| Topology | — |
| Package | — |
| Operating Temp | °C |
| Protection | — |
Applications
Request Quote — In Stock, 100% New & Original, Full Warranty
TPS79118DBVR: 1.8 V, 100 mA, 15 uV noise in a five pin SOT-23
The TPS79118DBVR is the 1.8 V fixed member of the TPS791 line from Texas Instruments, a 100 mA linear regulator with 70 dB of rejection at 10 kHz, 15 microvolt RMS of output noise with a 0.1 uF bypass capacitor, and a 63 microsecond start up. It sits in the five pin SOT-23 package coded DBV, 3000 pieces per reel, and it is specified over a junction range of -40 to 125 degrees with a 1.764 V to 1.836 V output window at room temperature.
Two details in this device decide whether it drops into an existing board. The first is the enable polarity: on the TPS791 an enable pin pulled low turns the regulator on, so a board wired for an active high enable will hold the rail off. The second is that the dropout figure for the 1.8 V point is not a measured number at all. The data sheet states that the minimum input of 2.7 V governs this member, so a 3.3 V bus leaves 1.5 V of headroom and dropout never enters the budget. The same footnote explains why the 1.8 V and 3.3 V rows of the dropout table look lower than the 4.7 V row.
Key electrical data for the 1.8 V point
| Output voltage | 1.8 V fixed, 1.764 V to 1.836 V window at 25 C, 0 to 100 mA |
| Output current | 100 mA, current limit 285 mA to 600 mA |
| Input range | 2.7 V to 5.5 V, 2.7 V is the binding floor for this voltage |
| Quiescent current | 170 uA typical across the load range, 250 uA maximum |
| Noise | 17 uV RMS with a 0.01 uF bypass, 15 uV RMS with 0.1 uF, 100 Hz to 100 kHz |
| Rejection | 75 dB at 100 Hz and 100 mA, 72 dB at 10 kHz, 45 dB at 100 kHz |
Package, marking and reel data
| Body | SOT-23 DBV, 5 pins, 2.90 mm by 1.60 mm |
| Reel | 3000 pieces, large tape and reel |
| Finish and moisture | NIPDAU, level 1, unlimited floor life |
| Marking | PERI |
| Thermal resistance | 192.6 C per W junction to ambient in the five pin body |
Where an ultra low noise 1.8 V rail is used
The TPS791 line was written for voltage controlled oscillators, phase locked loops, Bluetooth and wireless LAN front ends, and portable instruments where the analog supply sits next to a switching converter. A 1.8 V rail at 100 mA is the classic core and analog supply of a handheld radio, a GPS module or a medical sensor front end, and the reason to spend a linear regulator on it is the noise floor. At 15 microvolt RMS the regulator is below the input referred noise of most low noise amplifiers that draw their bias from the same rail, and at 45 dB of rejection at 100 kHz it removes the residue of a 1 MHz switching stage well enough that a following low noise amplifier does not see it as a spurious tone.
The bypass pin is what makes the noise figure real. The data sheet quotes 32 microvolts with a 0.001 uF capacitor, 17 with 0.01 uF and 15 with 0.1 uF, so a buyer who omits the bypass capacitor gets the top of that range rather than the headline number. The same pin sets the start up ramp, and the 63 microsecond figure quoted in the features list is measured with a 0.001 uF capacitor, which is the value to use when the rail has to come up inside a sequencer window.
Current budget is the other half of the decision. 170 uA of quiescent current is modest by modern standards, but on a battery instrument that sleeps for hours the standby figure matters more than the active one, and the TPS791 drops to 0.07 uA typical, 1 uA maximum, when the enable pin shuts the output down. A board that keeps this regulator alive through a 10 year shelf life has to hold that 1 uA maximum in the budget rather than the typical number.
Buyer questions on this order code
Is the enable active high or active low? Active low. Pulling the enable pin below 0.7 V turns the regulator on, and a logic high above 2 V puts it in shutdown. An active low enable is common on the older TPS791 and TPS797 lines and is the single most frequent reason a drop in replacement does not behave as expected.
Can this part run from a 5 V bus? Yes, the input ceiling is 5.5 V and the input current at 1 mA of load is small. The dissipation at 100 mA from 5 V to 1.8 V is 0.32 W, which on a 192.6 C per W five pin body is a 62 degree rise. That is inside the rating but it is the limit of what the package should carry without a copper pour under the pin.
What replaces the TPS79118 when it disappears? The TPS792 and TPS793 families are the direct relatives, with the same 1.8 V trim, a higher current in the TPS793 case and an active high enable. The cross reference table lists the pin and function differences before any substitution is quoted, because the enable polarity and the bypass pin are not always present on the alternative.
Sourcing the TPS79118DBVR through SUPERB
SUPERB supplies this part against the order code rather than against a generic 1.8 V description, because the DBV five pin body, the PERI marking and the level 1 moisture class are what a line audit checks. Every shipment carries the date code, the reel label and a certificate of conformance, and the parts are inspected on receipt for marking and packaging before they enter stock.
When the 1.8 V point is no longer available in this family, the answer is a documented comparison rather than a guess: the pin to pin cross reference page lists the candidates and the pins that change, and obsolete RF part replacement covers the end of life route for parts like this one. Send the annual quantity and the rail conditions and the quote comes back with the substitute stated.
