TPS563231DRLR
Product Specifications
TPS563231DRLR
Texas Instruments — Power Management & Signal Chain
Product Overview
The TPS563231DRLR from Texas Instruments is a power management / signal chain IC delivering high efficiency, precision regulation, and robust protection. Texas Instruments (TI) is a global leader in analog ICs, power management solutions, and embedded processors.
Superb Automation partners with leading brands including Qorvo, TI, ADI, XILINX, NVIDIA, Intel, ST, MACOM, Renesas, and Coilcraft to provide complete BOM and supply-chain solutions.
Key Features
- High-efficiency power conversion with low quiescent current
- Wide input voltage range with precision output regulation
- Integrated over-current, over-temperature, and short-circuit protection
- Small footprint packaging for space-constrained designs
- AEC-Q100 qualified options available for automotive applications
- Flexible sequencing and soft-start control
Key Specifications
| Input Voltage | V |
| Output Voltage | V |
| Output Current | A |
| Switching Frequency | kHz |
| Efficiency | % |
| Quiescent Current | µA |
| Topology | — |
| Package | — |
| Operating Temp | °C |
| Protection | — |
Applications
Request Quote — In Stock, 100% New & Original, Full Warranty
TPS563231DRLR: a 3 A synchronous step down converter in a 1.6 mm SOT-563 body
TPS563231DRLR is a synchronous step down converter with the D-CAP3 loop, both switches and an internal soft start in a six pin body in a SOT-5X3 (DRL) body of 6 pins. It takes 4.5 V to 17 V in and delivers 3 A at an output from 0.6 V to 7 V with a 600 mV reference and 2 per cent accuracy at 25 C. The switches are 95 milliohm high side and 55 milliohm low side, the switching frequency is 600 kHz, and the loop is internal with no compensation parts, which is why the whole rail fits in six pins. Light load operation is a pulse skip mode, shutdown current is under 12 microamp, and the part starts into a pre-biased output without pulling it down.
Order code and package
| TPS563231DRLR | SOT-5X3 body of 6 pins measuring 1.60 mm by 1.60 mm by 0.55 mm, 4000 pieces on a large reel, moisture level 1 at 260 C with unlimited floor life, marking 3231, active status in the package addendum |
| TPS563231DRLT | the same die on a 250 piece small reel, which is the string a pilot line or a repair bench orders |
| Pin count | 6 pins with no thermal pad, so the heat leaves through the pins and the copper they land on |
| Feedback | an external divider against 600 mV, so the output is set between 0.6 V and 7 V by two resistors |
| Mode | pulse skip at light load, entered automatically, with no mode pin to select it |
| Body | the smallest of the family at 1.6 mm square, which is what allows a 3 A rail to sit beside a connector |
Electrical parameters that decide the application
| Input voltage | 4.5 V to 17 V in the recommended table, with an undervoltage lockout at 4.0 V to 4.3 V rising and 3.3 V to 3.6 V falling |
| Output voltage | 0.6 V to 7 V set by a divider against a 588 mV to 612 mV reference at 25 C, which is the 2 per cent figure |
| Output current | 3 A continuous, with the copper under the six pins deciding how much of that survives at the ambient inside the enclosure |
| Switch resistance | 95 milliohm high side and 55 milliohm low side at 25 C with a 5 V gate drive, which is why the low duty cycle rails are the efficient ones |
| Current limit | 3.0 A minimum, 3.9 A typical and 4.8 A maximum on the low side switch, so a 3 A load sits at the bottom of the window |
| Switching frequency | 600 kHz fixed, which sets the inductor and the ripple for a given output capacitor |
| Supply current | 220 microamp typical and 300 microamp maximum while enabled and not switching, which is the standing load on the input rail |
| Shutdown current | 2 microamp typical and 12 microamp maximum with the enable low |
| Soft start | 1.5 ms internal ramp, fixed, which limits the inrush into the output capacitor at every start |
| Minimum on time | 80 ns, and minimum off time 250 ns, which together set the duty cycle range at 600 kHz |
| Enable thresholds | 1.10 V to 1.42 V for a high and 1.00 V to 1.30 V for a low, with a 1000 kilohm resistance to ground on the pin |
| Thermal shutdown | 160 C with 25 C of hysteresis, as the last protection |
| Pre-biased start | the part starts into an output that is already charged without discharging it first, which matters on a rail with a backup supply behind it |
Protection and operating behaviour of this converter
| TPS563231DRLR | this member, 3 A, 4.5 V to 17 V input, 600 kHz, 6 pin SOT-5X3, 4000 pieces on a large reel |
| TPS563231DRLT | the same die on a 250 piece small reel, which is the string a pilot line or a repair bench orders |
| Loop | D-CAP3 internal, stable with ceramic output capacitors, with no compensation network on the board |
| Light load | pulse skip entered automatically, which keeps efficiency up and lets the ripple change with the load |
| Current limit | 3.0 A minimum on the low side, so a 3 A load sits at the bottom of the window rather than in the middle of it |
| Start behaviour | starts into a pre-biased output without pulling it down, which matters on a rail with a backup supply behind it |
| Thermal | no pad on the six pin body, so the heat leaves through the pins and the copper they land on |
Points to check before this part goes on a BOM
3 A on a 1.6 mm body is a copper statement. There is no thermal pad on the six pin body, so the heat leaves through the pins. The copper the pins land on is the only thing between a 3 A rail and a thermal fold back, and the vendor application section shows the area that is needed.
The current limit window is tight against the rating. The low side limit is 3.0 A minimum, so a 3 A load is at the very bottom of the window and a rail that asks for slightly more will current limit. A board that needs margin should plan for 2.5 A rather than 3 A.
D-CAP3 means no compensation parts and no ESR requirement. The loop is internal and stable with ceramic output capacitors, which removes the network that an older converter needs and removes the dependence on the capacitor ESR that used to set the loop.
Pulse skip is automatic. At light load the part skips cycles to keep the output up, which gives good efficiency and a ripple that changes with load. A rail that needs a fixed ripple spectrum at light load needs a different part with a forced PWM option.
The 17 V input ceiling leaves little room on a 15 V bus. A 15 V rail with a transient above 17 V needs a clamp, and a 12 V rail with a load dump above 17 V needs one for the same reason. The lockout at 4.0 V is the other end of the same window.
Starting into a pre-biased output is not a detail on a redundant rail. A rail that is held up by a second supply while this converter starts does not get pulled down, so the load does not see a dip that would reset it.
What a six pin converter changes on a dense board
A 3 A rail used to need a controller, two external switches, a compensation network and a bootstrap diode. Six pins with the switches and the loop inside means the rail is the inductor, the capacitors, two feedback resistors and the part, which is often the difference between fitting a rail beside a connector and adding a board layer.
The cost is that nothing is adjustable. The frequency is fixed, the soft start is fixed and the loop is fixed, so the rail performs the way the vendor specified and the board cannot tune it.
Where the 600 kHz frequency sits in an emissions scan
600 kHz puts the first harmonics in the low hundreds of kilohertz, which is inside the band that a conducted emissions scan measures hardest. The internal loop and the ceramic output capacitor keep the ripple small, and the input capacitor placement is what decides the rest.
Where this order code fits
a set top box, a monitor or an industrial controller that needs a 3 A rail from a 12 V bus in a small area Teams comparing it with a neighbouring part start from our Power Management Cross Reference page, and teams replacing a part that has gone end of life start from the How to Reduce Component Cost page.
Questions buyers ask
Does this part need a compensation network? No. The D-CAP3 loop is internal and stable with ceramic output capacitors, so the rail is the part, the inductor, the capacitors and two feedback resistors.
What current can it really deliver? 3 A electrically, but the low side current limit is 3.0 A at its minimum, so the load should sit below that with margin. The copper under the six pins decides the thermal side.
Is the switching frequency adjustable? No, it is fixed at 600 kHz. There is no frequency resistor and no synchronisation pin.
What happens at light load? The part enters pulse skip mode automatically, which keeps efficiency up. The ripple changes with the load in that mode, so a rail that needs a fixed ripple spectrum needs a forced PWM part.
Can it start into a charged output? Yes, the pre-biased start behaviour keeps the converter from pulling the output down before it takes over.
How is it packed? 4000 pieces on a large reel for the R suffix and 250 pieces on a small reel for the T suffix, both at moisture level 1 with unlimited floor life.
