SN65C3232EDR: two driver two receiver RS-232 port from a single 3 V to 5.5 V rail
SN65C3232EDR is a dual RS-232 line driver and receiver with an on-chip dual charge pump in a SOIC body of 16 pins. It turns two UART pairs into RS-232 levels and generates the positive and negative rails itself from four small capacitors, so the board needs one supply instead of the plus and minus rails an older transceiver expects. The DR order code is the 16-pin SOIC on tape and reel.
Order code and package
| Order code | SN65C3232EDR |
| Package | 16-pin SOIC, D body, 9.90 mm by 3.91 mm |
| Packing | tape and reel |
| Drivers and receivers | two drivers, two receivers, one shared charge pump |
| Supply | 3 V to 5.5 V on VCC, single rail |
| External parts | four capacitors plus the standard 5 kohm input network on the line side |
| Pinout | C1+ pin 1 through VCC pin 16, the same arrangement as the common 16-pin RS-232 parts |
Electrical parameters that decide the application
| Supply current | 0.3 mA typical and 1 mA maximum with no load |
| Driver output swing | plus or minus 5 V minimum into a 3 kohm load to ground |
| Data rate | up to 1 Mbit/s |
| Driver slew rate | 14 V per microsecond to 150 V per microsecond over load and temperature |
| Power-off output resistance | 300 ohm minimum, so the port does not load a powered line |
| Short circuit current | plus or minus 35 mA on a driver output |
| ESD on the line pins | plus or minus 15 kV HBM and IEC air gap, plus or minus 8 kV IEC contact |
| Temperature | minus 40 to plus 85 degrees Celsius |
Family variants and how they differ
| SN65C3232E | minus 40 to plus 85 degrees, the industrial grade in this page title |
| SN75C3232E | 0 to plus 70 degrees, the commercial grade of the same die |
| D, DB, DW, PW | SOIC wide body, SSOP, SOIC and TSSOP bodies of the same circuit |
| Charge pump | one positive and one negative converter, both from the VCC rail |
Points to check before this part goes on a BOM
The four capacitors are not the same at every rail. At 3.3 V the data sheet asks for four 0.1 microfarad parts, while at 5 V it asks for 0.047 microfarad on C1 and 0.33 microfarad on C2, C3 and C4. A board that keeps the 3.3 V values on a 5 V rail runs the pump with less stored charge per cycle, which shows up first as a smaller negative swing under load.
The requirement is plus or minus 5 V into 3 kohm. The RS-232 receiver threshold is plus or minus 3 V, so the part nominally clears it by 2 V, but that margin is measured at the driver pin. A long cable with 2500 pF of capacitance and a 3 kohm far end load is the worst case in the standard, and that is where the 1 Mbit/s figure stops being reachable.
At 1 Mbit/s the bit period is 1 microsecond and the specified slew window of 14 to 150 V per microsecond decides the eye. A 10 V transition at 150 V per microsecond takes 67 ns, which is 7 percent of the bit, while the same transition at the slow end takes 714 ns and leaves 286 ns of flat top. Both ends of that window are inside the specification, so the cable and not the part sets the rate a product can actually use.
The 0.3 mA typical supply current is a no load figure. Each driver switching at 1 Mbit/s into a 3 kohm load draws roughly 3.3 mA of average load current at 10 V of swing, so a two driver port at full rate is a 7 mA to 10 mA consumer on the 3.3 V rail, and the 1 mA maximum in the table describes an idle line rather than a busy one.
There is no enable or shutdown pin on this order code. The port is live whenever VCC is present, which is acceptable for a fixed instrument but expensive in a battery product that keeps the rail up for other reasons. Products that need the port to disappear from the bus have to switch VCC with a load switch or choose a transceiver that carries an enable input.
The 15 kV rating belongs to the serial port pins, including ground. The logic side is a different number and a much lower one. An exposed DB9 or a terminal block that a technician touches needs its own transient protection and a series resistor into the line pins, because the internal diodes are sized for the IEC test waveform and not for a repeated surge on an outdoor cable.
The power-off output resistance of 300 ohm minimum is what keeps a powered down board from sinking current out of a live bus. It is a minimum, not a typical, so a second board on the same cable that is switched off presents at most 300 ohm to ground per line, which the active driver can still drive; a bus with five unpowered nodes in parallel is a 60 ohm load and is outside what any RS-232 driver is specified for.
The dual charge pump is the reason the part needs only a single rail, and it is also the reason the negative output is weaker than the positive one. V- is generated from the same VCC through one flying capacitor, so its magnitude falls faster as load current rises. A product that drives a long line at high rate should check the negative swing at the far end of the cable, not at the pin.
The 16-pin body is offered in four outlines in this family: D, DB, DW and PW. The DB is the narrow SSOP at 6.20 mm by 5.30 mm, the DW is the wide SOIC at 10.3 mm by 7.50 mm and the PW is the TSSOP at 5.00 mm by 4.40 mm. The electrical part is the same; the outline decides whether the part fits an existing pad ring or needs a new one.
The receiver input resistance is the 5 kohm that the RS-232 standard specifies, and the threshold is set so an open input reads as a mark. A cable that is left disconnected therefore produces a defined idle level rather than random characters, which is the behaviour a service port needs when a technician plugs in halfway.
Where this order code fits
It is used in industrial PCs, wired networking gear, point of sale terminals and battery powered instruments where a service port has to survive field handling. Teams comparing it with a neighbouring part start from our Pin to Pin Cross Reference page, and teams replacing a part that has gone end of life start from the How to Verify a Drop in Replacement page.
Questions buyers ask
Does the 5 V part work on a 3.3 V rail? Yes. The supply range is 3 V to 5.5 V and the logic inputs accept 5 V signals even when VCC is 3.3 V, so the same reel serves both rails. Only the four charge pump capacitors change value between the two cases.
Is it a drop-in for the older 16-pin RS-232 parts? The pin arrangement matches the common 16-pin parts, including the C1, V+, C1 minus, C2 and V minus positions, so the footprint is shared. The supply current and the ESD ratings differ between vendors and have to be checked against the drawing rather than assumed.
How much current does a two channel port draw at full rate? Budget 7 mA to 10 mA on 3.3 V for both drivers loaded at 3 kohm and switching continuously. The 0.3 mA in the table is the no load figure and is not the number for a working port.
What happens below 3 V? The pump cannot hold plus or minus 5 V and the output swing falls with the rail. Operation below 3 V is outside the recommended range, so a 3.0 V rail at minus five percent is already a fault condition for the port.
