DRV8601DRBR: A 400 mA Haptic Driver With a 100 us Turn On for Button Feedback

DRV8601DRBR is a single supply haptic driver for eccentric rotating mass motors and linear resonant actuators in a VQFN (DRB) body of 8 pins. It runs from 2.5 V to 5.5 V directly from a lithium cell, delivers 400 mA into the actuator, and reaches full output within 100 us of the enable signal. The output stage is differential with a fixed gain of 2 V per V, so a 3.3 V supply gives plus or minus 4.55 V across the motor at 400 mA. The part exists for one reason: a phone that buzzes 30 ms after the tap feels broken, and the turn on time is what decides whether the feedback lands with the press.

Order code and package

Ordering stringDRV8601DRBR, VQFN, large reel
Family documentDRV8601, SLOS629D, July 2010, revised October 2016
PackageVQFN (DRB), 8 pins, 3 mm by 3 mm
Ball optionZQV, 8 ball WCSP, same die, different footprint
Ambient rangeminus 40 to plus 85 degrees
Junction rangeminus 40 to plus 150 degrees
Storage rangeminus 65 to plus 150 degrees
Enable pin1.8 V compatible, so it can be driven from a modern baseband or sensor hub
Output typedifferential, drives the actuator between OUT+ and OUT minus
Inputsingle ended PWM, duty cycle sets the drive level

Electrical parameters that decide the application

Supply range2.5 to 5.5 V, absolute maximum 6 V
Quiescent current1.7 mA typical, 2 mA maximum, no load
Shutdown current10 nA typical, 0.9 uA maximum
Turn on time100 us from enable to full output
Output current400 mA at 5 V, 300 mA at 3.3 V, 200 mA at 2.5 V
Differential output at 5 V and 400 mAminus 4.55 V and plus 4.55 V
Differential output at 3.3 V and 300 mAminus 2.87 V and plus 2.87 V
Differential output at 2.5 V and 200 mAminus 2.15 V and plus 2.15 V
Gain2 V per V, fixed
Output offset9 mV maximum, measured differentially
Input impedance2 MOhm
Enable high threshold1.15 V minimum
Minimum load impedance6.4 Ohm
Junction to ambient, VQFN52.8 C per W
ESD, human body modelplus or minus 4000 V

Family variants and how they differ

DRV86012.5 to 5.5 V, 400 mA, PWM input, the part on this page
DRV26032.5 to 5.5 V, LRA and ERM, auto resonance, PWM and enable only
DRV2604I2C control with a RAM waveform store, no licensed library
DRV2605I2C control with the licensed Immersion library and smart loop
DRV2605Lthe same function at a lower supply floor for small cells
What the family addsbus control, effect libraries and resonance tracking
What stays the samethe differential output stage and the 100 us class turn on

Points to check before this part goes on a BOM

Turn on time is a system specification, not a data sheet detail. A linear resonant actuator needs roughly 50 to 80 ms to reach its resonant amplitude from rest, and an eccentric rotating mass motor needs 30 to 60 ms to spin up, so the 100 us of the driver is small compared with the mechanical response. What the driver can control is that it does not add to it. A driver that ramps its output over 5 ms, or that starts through a soft start, delays the whole feedback chain and the user feels a lag that is hard to trace back to the analogue part. Keeping the enable and the PWM input asserted together, with the PWM already at the required duty cycle, is what makes the 100 us figure real.

The differential output doubles the voltage across the motor for the same supply, and that is how a 3.3 V phone drives a 3 V rated actuator at full strength. With gain 2 and a 3.3 V rail, the pair swings plus or minus 2.87 V at 300 mA, which is 5.74 V across the load. The price is that the current is drawn from the supply continuously in both directions and the part dissipates the difference between the supply and the load. At 300 mA into a 10 Ohm actuator the load takes 3 V and the driver drops about 0.3 V per side, so the dissipation is roughly 0.18 W, which the 3 mm by 3 mm body handles with 52.8 C per W and a copper pad underneath.

The PWM duty cycle sets the amplitude and the frequency sets the feel. For an eccentric rotating mass motor the drive frequency is chosen near the mechanical resonance of the motor mount, usually between 150 and 250 Hz, and the duty cycle sets the strength. For a linear resonant actuator the frequency has to match the actuator resonance within a few hertz, and this part has no tracking loop, which is why the DRV2605 exists for that job. A product that uses the DRV8601 with an LRA has to calibrate the drive frequency per unit or accept a wide spread in amplitude, and that spread is the reason most LRA products move to a driver with auto resonance once the product reaches volume.

Protection is limited to output short circuit and thermal shutdown, and both matter in a product that is assembled by hand. A shorted flex tail or a pinched wire pulls the output to the current limit, and the part survives until the fault is removed rather than failing at power up in the factory. Thermal shutdown is the second line of defence for a stuck enable, which is a real failure mode when the enable line is shared with a test point. What the part does not have is any feedback path, so a host that needs to know whether the actuator is connected has to infer it from the supply current, and the 9 mV output offset is the only asymmetry that shows up in that measurement.

Choosing the actuator before choosing the driver

The driver has to match the actuator more than the actuator has to match the driver, and the two types behave differently. An eccentric rotating mass motor is a small DC motor with an offset mass, it reaches full amplitude in 30 to 60 ms, and its amplitude depends on the drive voltage, so the differential output of this part is a direct gain in strength. A linear resonant actuator is a spring and a mass driven at resonance, it reaches amplitude in 5 to 15 ms, and its amplitude depends on how close the drive frequency is to its resonance, not on how hard it is driven. The same driver can run both, but the LRA needs the frequency calibrated per unit, and that is the reason the two application notes for this part give different external component values.

Where this order code fits

Touch buttons, wearables, game controllers and any panel where a mechanical click has been replaced by a vibration. A team that only needs a fixed buzz from a PWM channel starts here; a team that wants stored effects or resonance tracking moves up the family. Teams comparing it with a neighbouring part start from our Power Management Cross Reference page, and teams replacing a part that has gone end of life start from the Component Lead Time Solutions page.

Questions buyers ask

Can it drive a small DC motor rather than a haptic actuator? It can, at up to 400 mA, but the output is a switching bridge with no current regulation, so a motor with a stall current above that limit needs a different driver.

What PWM frequency should be used? Above the audible band for the mechanical structure, typically 20 to 50 kHz, so the drive does not excite a buzz in the housing.

Is the enable pin tolerant of a 1.8 V GPIO? Yes, the high threshold is 1.15 V minimum, so a 1.8 V logic high is enough at every corner.

Does the part need output capacitors? No series capacitor is needed because the load is driven differentially, but a 1 uF bypass on the supply close to the part is required.
