TMS320F28335PGFA

Texas Instruments C2000™ Delfino™ — 32-Bit Digital Signal Controller, 150 MHz with Floating-Point Unit

Product Overview

The TMS320F28335PGFA is a high-performance 32-bit digital signal controller (DSC) from Texas Instruments' C2000™ Delfino™ family. Built on a 150 MHz C28x CPU with an integrated hardware IEEE-754 single-precision Floating-Point Unit (FPU), it delivers 150 MIPS of real-time processing throughput for closed-loop control applications. The device packs 512 KB of on-chip Flash memory and 68 KB of RAM, a 16-channel 12-bit ADC with 80 ns conversion time, 18 PWM outputs (6 with high-resolution 150 ps micro-step control), and a rich peripheral set including CAN 2.0B, SPI, I2C, SCI/UART, McBSP, and a 16/32-bit External Memory Interface (EMIF). Housed in a compact 176-pin LQFP (24×24 mm) package and rated for the full industrial temperature range (−40°C to +85°C), the TMS320F28335PGFA is engineered for demanding motor drives, digital power conversion, renewable energy systems, and advanced industrial automation.

Key Features

• 150 MHz C28x 32-bit CPU with hardware FPU — 150 MIPS, no software floating-point overhead

• 512 KB on-chip Flash (256K × 16), 68 KB SARAM — single-cycle access for time-critical control loops

• 16-channel 12-bit ADC — 80 ns conversion time, dual sample-and-hold, autosequencer

• 18 PWM channels: 6 HRPWM (150 ps resolution), 6 ePWM, 6 eCAP

• 2 Quadrature Encoder Pulse (QEP) modules for precision motor position/speed sensing

• Up to 88 individually programmable GPIO pins with input filtering

• Communication: 2× CAN 2.0B, 3× SCI/UART, 1× SPI, 1× I2C, 2× McBSP

• External Memory Interface (EMIF): 16-bit or 32-bit, supports SRAM, Flash, SDRAM

• 6-channel DMA controller for background data transfers without CPU intervention

• On-chip oscillator and PLL — external 30 MHz crystal to 150 MHz system clock

• Industrial temperature range: −40°C to +85°C (AEC-Q100 qualified variant available)

• 3.3 V I/O, 1.9 V core — low power consumption (typical ~300 mW at 150 MHz)

Key Specifications

• Manufacturer

• Texas Instruments

• Series

• C2000™ Delfino™ TMS320F2833x

• Core

• C28x 32-bit + Hardware FPU

• Max Frequency

• 150 MHz (6.67 ns cycle)

• Performance

• 150 MIPS / 150 MFLOPS

• Flash Memory

• 512 KB (256K × 16)

• SARAM

• 68 KB (34K × 16)

• Boot ROM

• 8K × 16

• OTP Memory

• 1K × 16

• ADC

• 16-ch, 12-bit, 12.5 MSPS, 80 ns conv.

• PWM

• 18 total (6 HRPWM @ 150 ps)

• QEP

• 2 modules

• Capture Inputs

• 6 (eCAP)

• GPIO

• Up to 88

• DMA

• 6-channel

• CAN

• 2× CAN 2.0B

• SCI (UART)

• 3×

• SPI

• 1×

• I2C

• 1×

• McBSP

• 2×

• EMIF

• 16/32-bit external bus

• Watchdog Timer

• Yes

• Supply Voltage

• 1.9 V core / 3.3 V I/O

• Operating Temperature

• −40°C to +85°C

• Package

• 176-LQFP (24×24 mm, 0.5 mm pitch)

• Mounting Style

• SMD / SMT

• RoHS

• Compliant

• Moisture Sensitivity

• MSL 3 (168 hours)

Applications

Why Choose TMS320F28335PGFA

The C2000 Delfino series has been the de-facto standard for real-time closed-loop control for over a decade. Unlike general-purpose MCUs that require software floating-point libraries (slow, non-deterministic), the TMS320F28335PGFA executes single-precision floating-point math in hardware — one instruction per clock cycle. This means complex algorithms like Park/Clarke transforms, PID loops with anti-windup, and sensorless FOC (Field-Oriented Control) run with deterministic timing, critical for motor control and power conversion where a few microseconds of jitter can cause instability. The on-chip 12-bit ADC's dual sample-and-hold and 80 ns conversion time enable simultaneous current and voltage sensing without external ADCs. Combined with the 150 ps high-resolution PWM, this chip can directly drive GaN and SiC power stages in modern high-frequency converters. With a mature ecosystem — Code Composer Studio IDE, controlSUITE libraries, TI's Digital Power and Motor Control SDKs — development time is measured in weeks, not months.

Alternative Parts

• TMS320F28335ZAYA

• Same core, 179-Ball NFBGA package

• TMS320F28335ZJZA

• Same core, 176-Ball BGA package

• TMS320F28335PTPS

• Same core, 176-HTQFP PowerPAD package

• TMS320F28377D

• Dual-core C28x + CLA, 200 MHz (next-gen upgrade)

• TMS320F280049C

• Single-core C28x, 100 MHz, lower-cost alternative

• TMS320F28379D

• Dual-core + dual CLA, 200 MHz, 1 MB Flash (premium)

Development Tools

• TMDSCNCD28335 — C2000 Delfino controlCARD (plug-in eval module)

• TMDSDOCK28335 — Delfino Experimenter Kit (full dev board)

• Code Composer Studio (CCS) IDE — free, Eclipse-based, with C2000 compiler

• controlSUITE — free software libraries: motor control, digital power, signal processing

• C2000Ware — device drivers, examples, and hardware abstraction layer

• XDS100 / XDS110 / XDS200 — JTAG debug probes
