TPS77050DBVR

Brand: Texas Instruments
Texas Instruments TPS77050DBVR is a power management component designed for AI Servers & Low-Altitude Economy (Drone and UAV) and related applications. In stock at Superb Automation — request a quote for competitive pricing and fast delivery.
quote now

Product Specifications

TPS77050DBVR — Power Management & Signal Chain | Superb Automation

TPS77050DBVR

Texas Instruments — Power Management & Signal Chain

Product Overview

The TPS77050DBVR from Texas Instruments is a power management / signal chain IC delivering high efficiency, precision regulation, and robust protection. Texas Instruments (TI) is a global leader in analog ICs, power management solutions, and embedded processors.

Superb Automation partners with leading brands including Qorvo, TI, ADI, XILINX, NVIDIA, Intel, ST, MACOM, Renesas, and Coilcraft to provide complete BOM and supply-chain solutions.

Key Features

  • High-efficiency power conversion with low quiescent current
  • Wide input voltage range with precision output regulation
  • Integrated over-current, over-temperature, and short-circuit protection
  • Small footprint packaging for space-constrained designs
  • AEC-Q100 qualified options available for automotive applications
  • Flexible sequencing and soft-start control

Key Specifications

Input VoltageV
Output VoltageV
Output CurrentA
Switching FrequencykHz
Efficiency%
Quiescent CurrentµA
Topology—
Package—
Operating Temp°C
Protection—

Applications

Industrial Automation Automotive Electronics Telecom Infrastructure Server & Data Center Power Medical Devices Consumer Electronics

Request Quote — In Stock, 100% New & Original, Full Warranty

TPS77050DBVR 50 mA regulator for rails that sleep

The TPS77050DBVR is the 5.0 V fixed member of the TPS770 family in the five pin SOT-23 body, rated at 50 mA. It is built for the rail that spends most of its life asleep: quiescent current is 17 microamp typical at room temperature with no load, which is the number that decides whether a battery powered instrument meets its standby budget. Dropout is quoted at 71 mV typical at 100 mA on the legacy silicon and 215 mV on the current silicon, and the input range reaches 10 V on the legacy part and 16 V on the current one.

The family document prints one text block for the 50 mA and the 100 mA members, so the load column in the electrical table is the one to read rather than the paragraph above it. What does not change between the two is the loop: both are stable with a small ceramic output capacitor, both have internal soft start, and both hold better than 70 dB of rejection at 1 kHz on the current silicon, which is enough to keep a switching converter's ripple out of a low current analogue rail without adding a filter.

Key parameters printed in the SLVS210E document

Input range2.5 V to 16 V on the current silicon, 2.7 V to 10 V on the legacy silicon
Output5.0 V fixed, fixed members from 1.5 V to 5.0 V in the family
Load current50 mA
Quiescent current17 microamp typical at 25 degrees with no load, 28 microamp at 100 mA of load
Dropout71 mV typical at 100 mA on the legacy silicon, 215 mV on the current silicon
Accuracy3 per cent over load and temperature on the legacy silicon, 1.2 per cent on the current silicon
RejectionBetter than 70 dB at 1 kHz and 46 dB at 1 MHz on the current silicon
Soft startInternal, so no external capacitor on a control pin is required

Package, reel and top side marking

PackageSOT-23, DBV body, five pins
Reel3000 pieces on a large tape and reel
Finish and moistureNickel palladium gold, moisture level 1, unlimited floor life
Temperature and markingMinus 40 to plus 125 degrees, top side marking PCYI

Where a 50 mA rail is the right size

A 50 mA rail is what a real time clock, a memory backup, a low power sensor and its reference draw together when the instrument is idle. The part is chosen on the idle current, not on the full load figure, because the load only wakes for a few milliseconds at a time. On the current silicon the input can sit at 16 V, which lets a 12 V battery stack feed the always on rail without a pre-regulator, and the legacy silicon at 10 V covers a 9 V battery. Both are stable with a ceramic output capacitor, which is the other reason the family survives in products that have been in the field for a decade.

The measurement to make before choosing it is the sleep current of the whole rail, not of the regulator alone. A 17 microamp regulator behind a 100 microamp divider is a divider problem, and moving to a lower quiescent part will not fix it. The second measurement is dropout at the lowest battery voltage, because the 5 V member needs 5.2 V at the input before it regulates on the current silicon, and a stack that sags below that at end of life will drop out of regulation before the cut off that the controller software expects; the safety stock planning page covers how a replacement generation is qualified when the legacy silicon is no longer on the reel.

Questions buyers ask before ordering

Which generation is on the reel? Both are Active. The current silicon carries the 16 V ceiling and the 1.2 per cent accuracy, the legacy silicon the 10 V ceiling and 3 per cent, so the drawing has to name one.

Can two of these be cascaded? Yes, and it is common: a 12 V to 5 V stage followed by a 5 V to 3.3 V stage keeps each dissipation low. Each stage needs its own output capacitor and its own soft start, which is internal on this part.

Is the SOT-23 body rated for 50 mA in still air? At 5 V in and 3.3 V out the dissipation is 85 mW, which the body holds comfortably. At 12 V in the same load is 435 mW, and that is where the copper area starts to matter.

Ordering this part through SUPERB

SUPERB supplies this regulator against a bill of materials line and states the generation the reel carries, because the input ceiling differs between them and a 12 V bus needs the current silicon. Send the rail, the idle current budget and the battery chemistry through the date code management page and the answer comes back with the generation, the reel size and the date code.
