DRV777DR: seven low side channels for motors, relays and coils

The DRV777DR is a seven channel low side driver in a 16 pin SOIC, packed 2500 pieces on a large reel. Each channel sinks 140 mA from a 5 V logic input or 100 mA from a 3.3 V input, the output can be pulled up to 20 V, and internal free-wheeling diodes with a common cathode on the COM pin handle the inductive kick from a relay coil or a unipolar stepper winding.

The part is the modern equivalent of a Darlington array, with one important difference: the outputs are low impedance and the saturation voltage is 0.36 V typical at 100 mA rather than the 1 V or more of an older Darlington stage. That matters in a 16 pin body with seven channels on at once, because the power that is not dissipated in the driver does not have to leave through the package.

With all seven channels in parallel the part can sink about 1 A, which makes it usable for a single larger load as well as for seven small ones. The logic inputs accept 1.8 V, 3.3 V and 5 V levels, so the same part works with a small microcontroller and with a 5 V legacy logic rail.

Key data for the DRV777DR

ChannelsSeven low side drivers with internal free-wheeling diodes to COM
Current per channel140 mA at 5 V logic, 100 mA at 3.3 V logic
Parallel currentAbout 1 A with all seven channels tied together
Saturation0.36 V typical and 0.49 V maximum at 100 mA
Output voltage20 V absolute maximum on the output and COM pins
Switching50 ns typical fall, 121 ns typical rise through the internal stage
TemperatureMinus 40 C to plus 125 C junction, 150 C absolute maximum

Body, packing and marking data

BodySOIC, 16 pins, the D outline
Packing2500 pieces on a large reel on the DR suffix, 2000 in the TSSOP body
FinishTin lead finish, moisture level 1 at 260 C, unlimited floor life
MarkingDRV777 on the body with the date code, no sensitivity or grade letters

The COM pin is not optional on an inductive load

Each output has a diode to the COM pin, and the COM pin is the common cathode of all seven. A relay coil or a stepper winding that is switched off has to have somewhere for its current to go, and that path is through the diode to COM and then to the supply rail. Leaving COM floating removes the protection and the first inductive switch-off will damage the output stage.

The COM pin and the outputs are rated to 20 V absolute maximum, which sets the ceiling on the rail that feeds the load. A 24 V relay coil cannot be driven directly by this part on a 24 V rail; either the load runs from 12 V or the board moves to a driver with a higher rating.

The ground pin current has its own limit, 700 mA continuous with the junction between 100 C and 125 C. Seven channels at 100 mA each reach that limit, so a board that runs all channels at once has to check the total rather than the per channel figure.

Where a seven channel driver earns its place

Unipolar stepper motors, relay banks, solenoid valves and LED strings are the four applications the vendor names. The seven channels suit a four phase stepper with three spare outputs for relays, which is why the part turns up on control boards that have to drive a mechanism and its indicators.

For boards that mix this driver with the logic that controls it, the one stop BOM sourcing page covers how the driver, the relays and the connectors are quoted together, and the kitting service page sets out how a mixed kit is kept together for a build.

Questions we get on this code

Can the outputs be paralleled for a bigger load? Yes, within the 700 mA ground pin limit and with the channels driven together so that they share the current evenly. Paralleling outputs that switch at different times does not share the load, it just moves it between channels.

Is the part a drop in for an older Darlington array? The pinout follows the same 16 pin arrangement, but the input current and the saturation voltage are different, and the internal diodes are already there. A board that relied on an external diode array can remove it, and one that relied on the higher input threshold of a Darlington should check the 1.65 V logic high level against its driver.

The last point is thermal. Seven channels at 140 mA and 0.4 V each dissipate about 0.4 W in the package, which the SOIC body can handle at 25 C but not inside a sealed enclosure at 85 C. Derate against the real ambient, not against the data sheet test condition.
