FX2 Ultimate Mini VTX PCBA

Ultra-Compact FPV Video Transmitter | Micro Drone / Tiny Whoop | 0201 SMT · Miniature RF PCB | Superb Automation

Product Overview

The FX2 Ultimate Mini is an ultra-compact FPV video transmitter designed for micro drones and tiny whoop-class aircraft where every gram and every millimeter counts. Unlike full-size VTX modules with separate heatsinks and SMA connectors, the FX2 Mini integrates RF PA, MCU, and antenna connection onto a miniature PCB — typically smaller than a postage stamp. Superb Automation provides precision SMT assembly for these extreme-miniaturization RF boards, where the manufacturing tolerances are as demanding as the design itself.

PCBA Manufacturing Challenges

1. 0201 Component Placement & Soldering

The FX2 Mini uses 0201-size (0.6×0.3 mm) passive components — resistors, capacitors, and inductors that are barely visible to the naked eye. Placement accuracy requires high-end pick-and-place machines with vision alignment capable of resolving 0201 packages. Solder paste printing demands ultra-fine-pitch stencils (0.08 mm thickness with laser-cut apertures) and automatic solder paste inspection (SPI) to verify deposit volume on every pad before component placement.

2. PCB Warpage Control at Micro Scale

At miniature PCB dimensions, even 0.1 mm of warpage across the board is significant relative to component size — causing tombstoning of 0201 passives or open joints on BGA/LGA packages. We use low-CTE laminates and symmetrical stackup design to minimize warpage through the reflow profile. Post-reflow flatness is verified by automated optical inspection (AOI) before electrical test.

3. RF Performance in Minimal PCB Area

The FX2 Mini's RF section — PA, matching network, and antenna feed — must fit within a fraction of the board area available on full-size VTX modules. This increases sensitivity to trace width variation and dielectric thickness tolerance. We maintain the same RF process controls as our full-size VTX assembly: impedance-controlled PCB fabrication with TDR coupon verification, and RF output power measurement on each assembled unit.

4. Thermal Management Without Heatsink

Unlike larger VTX modules that use dedicated heatsinks or fans, the FX2 Mini relies entirely on PCB copper pour and airflow for heat dissipation. We use maximum copper weight that the miniature trace/space rules permit, with thermal vias stitching the PA ground pad to inner and bottom copper layers. The PCB effectively becomes the heatsink — making copper thickness and via count critical design variables.

Superb Automation Assembly Capabilities — Micro VTX

Ordering Options

Send your micro VTX Gerber and BOM to pcba@superb-tech.com for a free DFM review. 0201 and micro-BGA assembly capability confirmed.
